Powering Your Next Project: A Guide to Private Pole Installations for Builders

As a builder, you face the challenge of balancing costs while dealing with client demands and coordinating tradespeople. Making informed infrastructure choices early in the construction phase helps minimise time delays, reworks, and costs.

Installing a private pole provides more control over your site’s infrastructure, but it comes with added considerations. Clearances, both overhead and underground, must be maintained, and it should be kept away from delivery trucks and operating cranes while adhering to network rules and standards.

If considering a private pole, consult with an experienced level 2 electrician for specific advice on location, power requirements, and clearances for trucks and cranes.

What you need to know about Private Poles for your new build

The location of your private pole will need to be within one metre of the property’s front boundary. This complies with Network Rules and ensures powerlines are safe from construction activities.

Things to consider when setting up a Private Pole

1. Site Specifics:
   • Placement of the new private pole
   • Whether the pole is temporary or permanent
   • Proximity to the supply network
   • Access for connection
2. Power Requirements:
   • Decide whether a single or three-phase connection is needed from the start. The choice between a single or three-phase connection will be determined by the power requirements of the building.
   • Pole Type i.e. steel, timber, composite

How to pick the right electrician for your project build

Private poles will need to be installed and connected by a Level II Accredited Service Provider. Level II ASP electrical contractors are qualified electricians with additional authorisations, enabling them to connect to the Electricity Network. They’re responsible for the installation of privately-owned private poles.

Ready to Power Up Your Project? Request a quote today for a clear cost breakdown tailored to your project needs. We will ensure your private pole installation aligns with your budget and safety requirements.

Private Pole Installation Process

Your electrician will conduct a site assessment, focusing on specific site requirements, such as ground conditions, future structures, existing Network assets, driveways, and crane slew.

Inspections and Applications: Inspect the site for potential interferences with other services or utilities. Submit an application to the local electricity Network for approval before commencing any work.

Pole Selection: Choose between timber, steel, or engineered cement poles, balancing durability and cost-effectiveness for construction projects. For temporary projects, consider a robust yet easily removable pole.

Site Preparation: Excavate for the pole’s foundation, ensuring sufficient depth for stability. In rocky areas, core drilling may be necessary. Truck access is required for timber and engineered cement poles.

Pole Installation: Use a hiab or crane for installing timber and engineered cement poles, aligning and stabilising them with concrete.

Electrical Connection: Install a single or three-phase connection based on the project’s power requirements, considering future scalability.

Safety and Compliance Inspection: Thoroughly test the electrical installation for safety and compliance. Check the earthing system, ensure proper cable insulation, and verify compliance with Australian and Network standards.

Project Documentation and Finalisation: Complete all necessary documentation, including notifications and compliance certificates. Leave the site clean and safe, integrating the pole installation into the project’s overall aesthetic.

Our Hassle Free Process

Valour Services understands the challenges of maintaining build standards across multiple construction sites. For builders and project managers, having a reliable partner to ensure compliance and reduce stress is crucial. We commit to upholding high standards and ensuring timely delivery aligned with your project deadlines.

Collaboration with reliable and qualified electricians is key to completing a build on or under budget. Valour Services offers an experienced team dedicated to understanding your specific needs. We will ensure your private pole is installed efficiently and correctly so that you can focus on your building project.

1. Review power requirements and pole location: Begin by discussing your specific power requirements and the ideal pole location.
2. Provide a quick quote and installation date: Receive a prompt quote and a set installation date for straightforward planning.
3. Submit Network applications and notifications: Manage all network applications and notifications for a smooth process.

We streamline the private pole installation process and offer a comprehensive package of additional services.

Types of Private Poles

Galvanised steel Private Poles

Galvanised steel poles are a popular and cost-effective option, suitable for most purposes. These poles are thinner in diameter, standing at an average height of 5-6m, and costing from $800. They have a lifespan of 10-15 years and are resistant to rot, fire and insect damage.

Installation of galvanised steel private pole

Due to their size and weight, these poles are the simplest to install. In most instances these poles can be erected within a few hours.

Hardwood timber Private Poles

Hardwood timber poles are often used when longer and larger cables need to be supported. Commonly used when power demand is greater than 100 Amps and when higher cable clearances are required. These poles usually range from 8-11 meters in height and are priced from $1500.

Installation of hardwood timber Private Poles

These privately owned poles are heavier and bulkier and require mechanical lifting. The pole location will need truck access for delivery and installation.

Engineered cement Private Poles

Engineered cement private poles are a newer option, offering several advantages over traditional poles. Priced from $1600, they’re known for their longevity and low carbon footprint. These poles are resistant to rot, rust, termites, and fire, and are non-conductive. The cables are concealed within the pole, which can be painted to suit aesthetic preferences.

Installation of engineered cement Private Poles

Similar to timber poles, engineered cement private poles require greater site preparation. The hole will need to be wider in diameter and it will need the use of a mobile crane to install. The initial cost is greater than steel poles but it comes with a lifetime warranty and has minimal maintenance requirements.

In summary, when choosing a private pole, consider the specific needs of your property, including installation location, aesthetic preferences, and budget. For further information, builders and property owners should contact a level 2 licensed electrician or electrical contractor.
